Deye 12,000 BTU Hybrid AC/DC Solar Air Conditioner
Powerful Cooling. Solar Energy. Lower Energy Costs.
The Deye 12,000 BTU Hybrid AC/DC Solar Air Conditioner is designed to deliver efficient and reliable cooling while making maximum use of available solar energy.
The system can be connected directly to solar panels, with a solar DC input range of 80–380 V, while also supporting 208–240 V AC grid power. This allows the air conditioner to utilize solar energy when available and use grid power when additional energy is required.
With a 12,000 BTU cooling capacity and an operating cooling range of approximately 2,700–13,500 BTU, the unit automatically adjusts its cooling output according to demand, helping improve energy efficiency and comfort.
Key Specifications
| SpecificationDetails |
|
| Capacity | 12,000 BTU |
| Cooling Capacity Range | 2,700–13,500 BTU |
| Cooling Power Input | 980 W nominal |
| Cooling Power Input Range | 150–1,250 W |
| Solar DC Input | 80–380 V DC |
| Grid Input | 208–240 V AC, 50/60 Hz |
| Model | DCGWA21-ACDCBLW-12KR2 |
| EER | 3.65 / 12.45 BTU/W |
| Indoor Unit Dimensions | 840 × 205 × 295 mm |
| Outdoor Unit Dimensions | 802 × 564 × 323 mm |
Why Choose the Deye Solar AC?
Direct Solar Connection
Connects directly to a suitable solar PV array without requiring a separate solar inverter for the AC's solar input.
Hybrid AC/DC Operation
Uses solar DC power and supports 208–240 V AC grid power, giving you greater flexibility and reliable cooling.
12,000 BTU Cooling Capacity
Designed for efficient cooling of suitable residential and commercial spaces.
Variable Power Consumption
Cooling power input ranges from approximately 150 W to 1,250 W, depending on operating conditions and cooling demand.
Wide Cooling Range
The cooling capacity can vary from approximately 2,700 to 13,500 BTU, allowing the system to adjust its output according to demand.
Ideal For
- Homes and apartments
- Offices
- Hotel rooms
- Retail shops
- Clinics
- Classrooms
- Small commercial spaces
- Other appropriately sized rooms
Simple Customer-Facing Description
Stay cool while spending less on energy.
The Deye 12,000 BTU Hybrid Solar Air Conditioner can connect directly to your solar panels and also supports 208–240 V grid power. With a cooling capacity of up to 13,500 BTU and variable power consumption of approximately 150–1,250 W, it intelligently adjusts its performance according to your cooling needs.
Use more solar. Reduce your dependence on grid electricity. Enjoy reliable cooling.
